POINT CLOUD TO REVIT MEP
Our team develops accurate Revit MEPF models by carefully transforming point cloud data into detailed 3D system layouts. We work in line with BIM execution plans and deliver models at LOD 200 to LOD 500 levels. These models cover all essential building systems — mechanical, electrical, plumbing, and fire protection — designed to fit the layout and zones of the structure perfectly.
We provide Revit MEP modeling services by using point cloud data to create detailed 3D models of mechanical, electrical, and plumbing systems for buildings, factories, plants, stations, electrical rooms, and more. Our models include complete layouts for ducts, pipes, fittings, cable trays, supports, and other essential components. We also add major equipment like HVAC systems, electrical panels, pumps, conveyors, towers, and electrical poles to ensure everything fits together accurately and works as planned.
Our team converts point cloud data into precise Revit MEP models, helping engineers and project teams make smarter decisions during design and construction. These models are useful for clash detection, smooth coordination between disciplines, accurate construction drawings, and efficient facility management throughout the building’s lifecycle.
We are specialized in accurately transforming Point cloud into a Revit MEP system for a range of clients, including 3D Laser scanning companies, Laser surveyors, building and Land surveyors, interior desingers, Architects, Consturation companies, Revit experts, MEP Engineers, BIM Freelancers, etc. We have experienced Revit MEP engineers who are well able to quickly convert Point cloud data to Revit MEP system with proper running pipe duct connections with fitting elements.
We have successfully completed 600+ Revit MEP high-detailed projects from the point cloud data such as Oil-gas, industrial plants, Machines, factories, hospitals, and many more. We create our MEP families for our MEP projects, especially for complex areas.
By creating an accurate and detailed model of a building’s MEP systems, we help ensure that the final product meets our client’s requirements, is efficient and functional, and can be easily maintained over time
While modeling pipe connections from point cloud data, we ensure high accuracy that perfectly aligns with the scanned data, resulting in reliable and high-quality 3D outputs. All pipe connections are properly linked and easy to identify, making the model more convenient for engineers, designers, contractors, and surveyors.
We also offer precise MEP quantity takeoff services to clients worldwide. Our expertise in delivering accurate building data supports smooth construction planning, material estimation, and cost control, making us a trusted 3D MEP BIM service provider across the globe.
We specialization lies in accurately creating Revit MEP system like Pipe, duct, fitting, cable tray, elbows, conduits etc from point clouds, with precision ranging from 2mm to 10mm, depends on point cloud quality. We achieve accuracy based on custom Revit MEP plugins, tailored for each project’s unique needs.
Project size and complexity vary, depending on factors like project type (factory, hospital, industrial plant, oil and gas facility), required detail level, and overall size. Our adaptable approach emphasizes collaboration, with teams ranging from 5 to 28 members. We prefer Revit’s collaboration tools for efficient teamwork.
We aim to expedite the completion of a 30-day project, targeting a timeframe of 12 to 15 days, it depends on the project’s complexity and requirements. For quick delivery, we prefer Revit collaboration tool, which allows us to have over 100 team members working on the same project at the same time.
MEP BIM Services
- Point cloud to Revit MEP conversion
- MEP Shop Drawings Creation
- MEP 2D Drafting Services
- MEP Fabrication Drawings
- MEP Coordination Services
- MEP BIM Modeling Services
- MEP Content Revit Family Creation
- 5D Cost Estimation
